Polyurethane High-Pressure Flexible Drain Hose DN400 Customized

HOME / PRODUCTS / Mining Dewatering Layflat Hose / Polyurethane High-Pressure Flexible Drain Hose DN400
Polyurethane High-Pressure Flexible Drain Hose DN400
  • Polyurethane High-Pressure Flexible Drain Hose DN400
  • Polyurethane High-Pressure Flexible Drain Hose DN400
  • Polyurethane High-Pressure Flexible Drain Hose DN400
  • Polyurethane High-Pressure Flexible Drain Hose DN400
  • Polyurethane High-Pressure Flexible Drain Hose DN400

Polyurethane High-Pressure Flexible Drain Hose DN400

Cover and Lining: TPU (Extrusion through-the-weave)
Reinforcement Layer: polyester fiber or aramid woven layer
Color: Black, Red, Blue, others on request
Temperature Range:-40℃ to 70℃ (-40℉ to 158℉)
Available Length: 30m (100ft) - 200m (660ft), others on request
Delivery Time: 15-60days
Product Origin: China

Contact Us

Related Products

Product details

Advantages
Low tensile deformation rate, excellent wear resistance, and a wide temperature range . It's also resistant to hydrolysis, UV rays and acid-base corrosion, ensuring a long service life. The design is lightweight and flexible with a quick-connect system.

Key Points
1. Our double-sided polyurethane hose is lightweight and flexible. It is wear-resistant and leading to a low total cost of ownership.
2. Reduced Overall Costs： ideal for applications requiring frequent movement.
Flexible Customization: The hose is available in diameters from 2 to 16 inches and can be customized for specific pressure, length, and color requirements to meet diverse needs.

Applications
Energy Extraction
Hydraulic Fracturing Water Supply: Large-diameter  hoses , withstanding high pressure.
Oil Transportation: Used for temporary oil pipelines, offering excellent leak and oil resistance.
Emergency & Municipal Services
Firefighting Remote Water Supply: Quickly deploys water systems to supply areas inaccessible to fire trucks.
Urban Drainage / Mine Dewatering: suitable for emergency dewatering in mines.

Structure parameters

ID

Inside diameter

Working pressure

Brust pressure

Wall thickness

Weight

inch

mm

MPa

BAR

PSl

MPa

BAR

PSI

mm

Kg/m

10

250

1.0

10

145

 3.0  30 435 3.4-3.9 3.2

10

250

1.3

13

188.5

 3.9 39 565.5 3.9-4.4 3.8

10

250

1.6

16

232

 4.8 48 696 4.8-5.2 4.4

10

250

2.0

20

290

 6.0  60 870 5.2  4.7

12

300

0.5

5

72.5

 1.5 15 217.5 2.1-2.3 2.6

12

300

1.0

10

145

 3.0  30 435 4.1-4.2 4.3

12

300

1.3

13

188.5

 3.9 39 565.5 4.3-4.4 4.8

12

300

1.5

15

217.5

 4.5 45 652.5 4.5-4.6 5.1

14

350

1.0

10

145

 3.0  30 435 4.3-5.0 5.52

16

400

1.0

10

145

 3.0  30 435 4.7-5.2 7

Note: Parameters such as inner diameter, wall thickness, weight, pressure and color can be customized according to customer requirements.
**All above technical parameters are for reference, details please confirm with JINLUO NEW MATERIAL.
